High-Power Simple Motor Controller G2 24v12

by Pololu
SKU 2988
£99.99 inc VAT
£83.33 ex VAT
1 in stock.

More available in 5-7 days.
Available for backorder (more info)

This powerful motor controller makes basic control of a brushed DC motor easy, with quick configuration over USB using the free software. It supports five control interfaces: USB, TTL serial, I²C, analogue voltage (potentiometer), and hobby radio control (RC). This version offers a wide 6.5 V to 40 V operating range and can deliver continuous output currents up to 12 A without a heat sink. Male headers and terminal blocks are included but not soldered, allowing for custom installations.


High-Power Simple Motor Controller G2 24v12

  • Motor Channels: 1
  • Control Interface: USB, Non-inverted TTL Serial, I2C, RC Servo Pulses, Analogue Voltage
  • Minimum Operating Voltage: 6.5V
  • Maximum Operating Voltage: 40V
  • Continuous Output Current per Channel: 12A
  • Maximum PWM Frequency: 22.5 kHz
  • Maximum Logic Voltage: 3.3V
  • Reverse Voltage Protection: Y
  • Connections Soldered: No
  • Size: 2.1" x 1.1" x 0.42"

Key features of the SMC G2 family

  • Simple bidirectional control of one brushed DC motor
  • Five communication or control options:
    1. USB interface for direct connection to a PC
    2. Logic-level (TTL) serial interface for use with a microcontroller
    3. I²C interface for use with a microcontroller
    4. Hobby radio control (RC) pulse width interface for direct connection to an RC receiver or RC servo controller
    5. 0 V to 3.3 V analogue voltage interface for direct connection to potentiometers and analogue joysticks
  • Simple configuration and calibration over USB with a free configuration program for Windows
  • Reverse-voltage protection
  • Hardware current limiting with a configurable threshold
  • Current sensing
