PCB Fabrication Sampler Pack

DESCRIPTION

This PCB Fab-in-a-box sampler pack has 4 different types of PCB laminate for DIY printed circuit board fabrication. The pack is great for trying out which laminate works best for your project and minimises your prototyping costs. The PCB fab sampler pack contains 4 x 20.5cm x 15.5cm copper/fibreglass sheets that are suitable for SMD components.

Included in the pack are 2 types of flexible single sided and double sided copper/fibreglass laminated sheets to make bendy PCBs and 2 types of thick single sided and double sided copper/fibreglass rigid sheets.

PCB fabrication

The process of transferring toner by re-fusing an image to a copper surface began back in the early 90s. It has come a long way since then, turning it from an 'art' to a 'science' as a dependable, repeatable, high resolution method for instant PCB fabrication.

PulsarProFx's "DirectETCH" process technique has adopted one specific specification to funnel all of these variables down to one simple board to use for all of your board fabrication requirements.

New product design normally goes through several iterations before everything fits exactly right. Why send off for expensive "proto" PCBs for each redesign or component reposition? PCB Fab-In-A-Box® allows you to make change after change without the high expense and long wait times of multiple "proto" boards being sent out to be fabricated. DIY and save a bundle of time and money.

FEATURES

4 panels 6" x 8" FR-4/G10 1/2 ox copper

• 1 x Flex .005" thick Single sided
• 1 x Flex .005" thick Double sided
• 1 x Carrier board .020"
• 1 x Rigid .032" thick Single sided
• 1 x Rigid .032" thick Double sided

RESOURCES

• "Direct Etch" technique for PCB fab
• PCB fab Guide
